Building Information Modeling

LTS Drafting and Engineering offers 3-D, real-time, modeling software used to increase productivity in building design and construction. LOD 350.

BIM Submittal Type 1

  • Consists of punched openings with standard connections
  • Minimal clash meetings required
  • Main purpose: As-built model

BIM Submittal Type 2

  • Complicated construction
  • Multi-story curtain wall
  • Custom anchors into building structure
  • Clash meetings on a weekly basis
